Figure 4 Modular 3D Printing Materials | 3D Systems

The 3D Systems Figure 4 Modular system is designed for high-speed, scalable production, and the materials portfolio reflects this commitment to industrial performance. These Figure 4 resins are optimized to leverage the continuous DLP technology, offering exceptional print speed, part accuracy, and long-term environmental stability for a range of applications.

Whether you are consolidating manufacturing steps with Figure 4's general-purpose materials, requiring high heat deflection for tooling, or needing fire-retardant properties for electronics, the Figure 4 Modular materials deliver predictable, quality results. Browse the selection below to find the ideal cartridge for your next high-volume, functional part run
Resin, Figure 4 TOUGH-GRY 15, 2.5 kg

Resin, Figure 4 TOUGH-GRY 15, 2.5 kg

$480.20
$480.20
Resin, Figure 4 TOUGH-GRY 10, 2.5 kg

Resin, Figure 4 TOUGH-GRY 10, 2.5 kg

$529.20
$529.20
Resin, Figure 4 Tough FR V0 Black, 2.5kg

Resin, Figure 4 Tough FR V0 Black, 2.5kg

$803.60
$803.60
Resin, Figure 4 Tough Clear, 2.5 kg cartridge

Resin, Figure 4 Tough Clear, 2.5 kg cartridge

$666.40
$666.40
Resin, Figure 4 TOUGH-BLK 20, 2.5kg

Resin, Figure 4 TOUGH-BLK 20, 2.5kg

$529.20
$529.20
Resin, Figure 4 Tough 65C Black, 2.5kg

Resin, Figure 4 Tough 65C Black, 2.5kg

$744.80
$744.80
Resin, Figure 4 Tough 60C White, 2.5kg

Resin, Figure 4 Tough 60C White, 2.5kg

$744.80
$744.80
Resin, Figure 4 RUBBER-BLK 10, 2.5 kg

Resin, Figure 4 RUBBER-BLK 10, 2.5 kg

$666.40
$666.40
Resin, Figure 4 RUBBER-65A BLK, 2.5 kg

Resin, Figure 4 RUBBER-65A BLK, 2.5 kg

$666.40
$666.40
Resin, Figure 4 Rigid White, 2.5 kg

Resin, Figure 4 Rigid White, 2.5 kg

$666.40
$666.40
Resin, Figure 4 Rigid Gray, 2.5kg

Resin, Figure 4 Rigid Gray, 2.5kg

$666.40
$666.40
Resin, Figure 4 PRO-BLK 10, 2.5 kg

Resin, Figure 4 PRO-BLK 10, 2.5 kg

$666.40
$666.40
Resin, Figure 4 MED-AMB 10, 2.5 kg

Resin, Figure 4 MED-AMB 10, 2.5 kg

$676.20
$676.20
Resin, Figure 4 HI TEMP 300-AMB, 2.5 kg

Resin, Figure 4 HI TEMP 300-AMB, 2.5 kg

$803.60
$803.60
Resin, Figure 4 High Temp 150C FR Black, 2.5kg

Resin, Figure 4 High Temp 150C FR Black, 2.5kg

$803.60
$803.60

Figure 4 Modular Materials: Engineering for Production

The material selection for the Figure 4 system is curated to meet the needs of true production environments. These resins provide end-use properties, eliminating the need to transition from a prototype material to a manufacturing material. The modular architecture is supported by a cartridge-based delivery system, ensuring clean, easy material switching to maximize your machine’s throughput and versatility across different applications.

General Purpose & Durable Resins
This category of materials forms the backbone of the Figure 4 production platform, designed for robustness, high feature detail, and long-term use. They are suitable for functional prototypes, jigs, fixtures, and direct end-use components that require characteristics similar to traditional injection-molded plastics.

  • Figure 4 PRO-BLK 10: An excellent all-purpose, highly stable production plastic offering long-term mechanical stability for durable black parts.
  • Figure 4 Rigid (Gray & White): Provides a stiff, dimensionally accurate plastic for high-detail parts, enclosures, and tooling where low deflection is critical.
  • Figure 4 Tough (Clear, 60C, 65C): Engineered for high impact strength and moderate flexibility, these resins are ideal for parts that must endure repeated stress, such as snap-fits, master patterns, and functional test components.

High-Temperature & Fire-Retardant Resins

For applications that involve exposure to heat, chemicals, or strict safety standards, the specialized Figure 4 resins offer certified or extreme performance. These materials are indispensable for automotive, aerospace, and electronics manufacturing aids and components.

  • Figure 4 HI TEMP 300-AMB: Features one of the highest heat deflection temperatures (HDT) in DLP printing, making it perfect for tooling, hot-air functional testing, and parts requiring high thermal resistance up to 300ºC.
  • Figure 4 High Temp 150C FR Black: A high-temperature resin that combines thermal resistance with Flame Retardant (FR) properties, ideal for under-the-hood or electronics applications where safety and heat resistance are paramount.
  • Figure 4 Tough FR V0 Black: This material meets the UL94 V0 flammability standard, offering a tough, production-grade resin for electrical casings, internal components, and transport applications that require self-extinguishing characteristics.
advantage3d

Flexible & Rubber-Like Elastomers

The Figure 4 Modular system is capable of printing true elastomers with excellent compression, rebound, and long-term flexibility. These materials allow you to rapidly produce functional soft parts that traditionally require expensive molding processes.

  • Figure 4 RUBBER-65A BLK & RUBBER-BLK 10: These elastomeric resins are used for soft-touch handles, grips, seals, gaskets, and vibration dampening components. They mimic the mechanical performance of commercial rubber, providing high elongation and quick recovery.
advantage3d

Sacrificial & Casting Resins

These specialized resins are utilized for indirect manufacturing processes, enabling the production of parts with materials beyond the plastic capability of the Figure 4 printer itself.

  • Figure 4 EGGSHELL-AMB 10: This resin is designed for creating sacrificial patterns that can be easily removed or dissolved after use. It is primarily used for creating detailed RTV (Room Temperature Vulcanizing) molds for silicone or urethane casting.
